***ขาย Power Amp AUDISON รุ่น VRX6.420 Chrome Chadow ( 75W x 4ch +85W x 2ch ) Made in Italy สภาพสวยไม่มีซ่อม ***

Audison VRX6.420 Chrome Chadow

Technical features

POWER SUPPLY...............................................................................................11 ÷ 15 VDC

IDLING CURRENT.......................................................................................................2.6 A

IDLING CURRENT WHEN OFF............................................................................< 0.04 mA

CONTINUOUS NOMINAL POWER Tol..................................(+10%/-5%); 0.3% THD; 12 VDC

A,B,C stereo ch. on 4 Ohms..................................................2x65W + 2x65W + 2x80 (RMS)

CONTINUOUS POWER 6 CHANNELS Tol.............................(+10%/-5%); 1% THD; 12.6 VDC

A,B,C stereo ch. on 4 Ohms....................................................2x75W + 2x75W + 2x85 (RMS)

CONTINUOUS POWER 6 CHANNELS Tol..............................(+10%/-5%); 1% THD; 13.8 VDC

1) A,B,C stereo ch. on 4 Ohms................................................2x75W + 2x75W + 2x85 (RMS)

2) A,B,C stereo ch. on 2 Ohms...........................................2x120W + 2x120W + 2x150 (RMS)

3) A,B stereo ch. on 4 Ohms, C stereo ch. on 2 Ohms.............2x75W + 2x75W + 2x165 (RMS)

4) A,B stereo ch. on 4 Ohms, C stereo ch. on 1 Ohm...............2x75W + 2x75W + 2x250 (RMS)

CONTINUOUS POWER 5 CHANNELS Tol................................(+10%/-5%); 1% THD; 13.8 VDC

5) A,B stereo ch. on 4 Ohms, C bridged ch. on 4 Ohms...........2x75W + 2x75W + 1x330 (RMS)

6) A,B, stereo ch. on 4 Ohms, C bridged ch. on 2 Ohms..........2x75W + 2x75W + 1x500 (RMS)

7) A,B stereo ch. on 2 Ohms, C bridged ch. on 2 Ohms........2x110W + 2x110W + 1x430 (RMS)

CONTINUOUS POWER 3 CHANNELS Tol................................(+10%/-5%); 1% THD; 13.8 VDC

8) A,B,C bridged ch.on 4 Ohms..........................................1x240W + 1x240W + 1x300 (RMS)

9) A,B bridged ch. on 4 Ohms, C bridged ch......on 2 Ohms.1x220W + 1x220W + 1x430 (RMS)

THD DISTORTION (1 kHz; 90% Nominal Power)............................................................0.02%

IMD DISTORTION (90% Nominal Power)......................................................................0.04%

BANDWIDTH (-3dB; Nominal Power)................................................................2 Hz ÷ 70 kHz

S/N RATIO (A weighed - 1 VRMS input).....................................................................100 dBA

REMOTE IN............................................................................................................7 ÷ 15 VDC

REMOTE OUT................................................................................................12 VDC - 150 mA

INPUT SENSITIVITY (high)............................................................................0.15 ÷ 1.5 VRMS

INPUT SENSITIVITY (low)............................................................................0.50 ÷ 5.0 VRMS

INPUT IMPEDANCE..................................................................................................15 kOhms

LOAD IMPEDANCE (stereo) ch.A and ch.B........................................................8 - 4 - 2 Ohms

LOAD IMPEDANCE (bridged) ch.A and ch.B..........................................................8 - 4 Ohms

LOAD IMPEDANCE (stereo) ch.C.....................................................................8 - 4 - 2 -1 Ohm

LOAD IMPEDANCE (bridged) ch.C.....................................................................8 - 4 - 2 Ohms

SIZE (W x H x D) mm........................................................................................240 x 64 x 585

SIZE (W x H x D) inches......................................................................................9.4 x 2.5 x 23

INTERNAL FUSE...............................................................................................................80A

* รับซื้อหรือเทิร์นให้ราคาที่ยุติธรรม **ดูสินค้ารายการอื่นๆได้ที่เว็ป**http://www.audioexit9.com/

** ดูของได้ทิ่บ้านสวนนนท์ 2 ถนน บางกรวย-ไทรน้อยห่างจากสะพานพระราม 5 ประมาณ 2 ก.ม**   ราคา 2x,xxx
